Name Of the roller | Hardness | Thickness | Properties |
Sammying roller | 80 - 85 Shore A | 25mm |
Water Resistant. High Abrasion resistance. High Modulus for load bearing capacity. |
Setting roller | 60 - 75 Shore A | 15 - 25 mm |
Resistant to chemicals used in leather processing. High Abrasion resistance. High Cut resistance. |
Splitting roller | 40 - 50 Shore A | 25 - 30 mm |
Good Abrasion resistance. Good Cut resistance. |
Shaving roller | 35 - 40 Shore A | 20 mm |
Good Abrasion resistance. Good Cut resistance. |
Buffing roller and sleeves | 8 - 18 Shore A | 25 - 35 mm |
Good Abrasion resistance. High Cushion effect. |
Satilux (Ironing) roller | 60 - 70 Shore A | 20 mm |
Heat resistance upto 150 deg celcius. Stable hardness. |
Measuring roller | 60 - 70 Shore A | 10 - 15 mm |
Grooved according to the drawing. Good abrasion resistance. |
Name Of the roller | Hardness | Thickness | Properties |
Yarn Sizing Roller | 60 - 65 Shore A | 15 - 35 mm |
Resistant to modified starch, PVA, CMC and acrylates. Resistant to continous operating temperature upto 110 deg celcius. Stable hardness over continuous ageing. Resistant to abrasion caused by yarn. |
Woven Fabric Desizing Roller | 60 - 65 Shore A | 15 - 35 mm |
Resistant to chemicals like Enzymes, Wetting agents, Glauber salt. |
Woven Fabric Bleaching Padder Roller | 75 - 80 Shore A | 20 - 25 mm |
Resistant to chemicals like Sodium hydroxide, Soda ash. Resistant to Hydrogen Peroxide Bleaching agent. Resistant to refucers like Zinc Oxide, Sulphur Dioxide and other reducers. Stable hardness over continuous ageing. Resistant to abrasion caused by fabric" |
Woven Fabric Mercerizing Roller | 65 - 70 Shore A | 15 - 20 mm |
Resistant to strong Caustic soda (LYE) solutions. Resistant to sulphuric acid that is used to remove extra lye present. Stable hardness over continuous ageing. |
Woven Fabric Stenter Padder Roller | 75 - 80 Shore A | 20 - 25 mm |
Resistant to chemicals like Soda ash, Sodium chloride, Sodium hydroxide and other chemicals. Stable hardness over continuous ageing. Resistant to abrasion caused by fabric. |
Cloth Guide Roller | 75 - 80 Shore A | 12 - 15 mm |
Excellent Abrasion resistance. |
Knitted Fabric De-Watering Padder roller | 89 -93 Shore A | 12 - 15 mm |
High Modulus that can withstand high load pressure. Resistant to abrasion caused by the fabric. Even squeezing effect to remove the moisture. |
Knitted Fabric Pickup Padder roller | 82 - 87 Shore A | 12 - 15 mm |
Resistant to softner chemicals. Even squeezing effect, which can help the fabric to pickup 17- 20% softener. |
Knitted Fabric Compacting Rollers | 60 - 65 Shore A | 8 - 10 mm |
Special Rubber Compound. Outstanding Abrasion resistance. |
Name Of the roller | Hardness | Thickness | Properties |
Felt Rolls / Wire Guide Rolls | 70 Shore D | 8 - 12 mm |
Good abrasion resistance. Resistant to chemicals & solvents used in paper machine applications. |
Breast Roll | 70 Shore D | 15 mm |
High modulus and excellent abrasion resistance. Resistant to chemicals & solvents used in paper machine applications. |
Couch Roll | 35 - 40 Shore A | 25 - 35 mm |
Chemically stable. Resistant to demanding environments in the wet end of the paper machine. |
Bottom Press Rolls | 80 - 85 Shore A | 20 mm |
Excellent abrasion resistant. High modulus & High load bearing capacity. Resistant to water & chemicals used in the paper machine applications. |
Top Press Rolls | 70 Shore D | 15 mm |
Excellent Abrasion resistance. High modulus. Resistant to water & chemicals used in the paper machine applications. |
MG Touch Roller | 85 - 90 Shore A | 20 mm |
Excellent Abrasion resistance. High modulus. Heat Resistant upto 120C. High crack and ageing resistance. |
Coater Banking Rolls | 65 - 70 Shore A | 25 mm |
Superior surface uniformly. Excellent release characteristics. Resistant to chemicals & solvents used in paper machine applications. |
Name Of the roller | Hardness | Thickness | Properties |
Gravure Printing Rollers | 60 - 70 Shore A | 15 - 20 mm |
Resistant to swelling and crack. Resistant to Solvent based inks, UV inks. Resistant to reducers like Ethyl acetate, Butanol, IPA, Toluene & other chemical reducers. Stable hardness and dimension. |
Flexography Rubber Rollers | 55 - 65 Shore A | 15 - 20 mm |
Resistant to swelling and crack. Resistant to Solvent based inks, UV inks. Resistant to reducers like Ethyl acetate, Butanol, IPA, Toluene & other chemical reducers. Stable hardness and dimension. |
Lamination Rollers | 75 - 85 Shore A | 15 - 20 mm |
Resistant to high temperature operations. Low co - efficient of friction,which provides smooth surface. Uniform Hardness. |
Takeup Rollers | 70 - 80 Shore A | 20 mm |
Resistant to water. High Modulus to withstand tight nips. |
Godet Pressure Rollers | 80 - 90 Shore A | 12 - 15 mm |
Resistant to High Abrasion provided by the tapes. Resistant to cut. |
UV Printing Rollers | - | 15 mm |
Resistant to UV printing Inks and reducers. |
Name Of the roller | Hardness | Thickness | Properties |
Ink Transfer Roller | 30 - 35 shore A | 12 - 13 mm |
Resistant to all conventional inks. Good Transfer properties. |
Ink Ductor Roller | 30 - 35 shore A | 12 - 13 mm |
Resistant to all conventional inks. Good Transfer properties. |
Ink Form Roller | 30 - 35 shore A | 12 - 13 mm |
Resistant to conventional inks. Low heat buildup at high speed. |
Water Dampening Roller | 30 - 35 shore A | 12 - 13 mm |
Water Friendly |
Dampening Roller | 25 - 30 shore A | 12 - 13 mm |
Resistant to water & alcohol solutions. |
UV Offset Roller | 25 - 30/40 - 45 shore A | 12 - 13 mm |
Resistant to UV inks and reducers. |
Name Of the roller | Industry Type | Properties | |
Coating Roller | Abrasive |
Uniform coating of solvents to the sand paper. |
|
Humidification Roller | Abrasive |
High Abrasion resistant and good grip |
|
Flexing Machine Roller | Abrasive |
Good Abrasion resistant. Unifor hardness |
|
Sizer Dancing Roller | Abrasive |
High Abrasion resistant. |
|
Sheet Cutter Roller | Abrasive |
High Abrasion resistant. |
|
IDC Roller | Abrasive |
High Abrasion resistant. |
|
Fishnet Roller | Fishnet |
High Abrasion resistant and heat resistant |
|
Food Industry Roller | Food |
High Abrasion resistant and heat resistant |
|
Coating Roller | Plywood |
Very High Abrasion resistant and glue resistant. Grooved Roller |
|
Coil Car Roller | Steel |
High Load bearing resistant. Oil resistant |
|
Pinch Roller | Steel |
Oil Resistant. High Abrasion resistant |
|
Snubber Roller | Steel |
Oil Resistant. High Abrasion resistant |
|
Contact Roller | Steel |
Oil Resistant. Grooved Roller |
|
Squeezer Roller | Steel |
Resistant to Dilute Nitric Acid |
|
Pickling Roller | Steel |
Resistant to Acids and Alkalis |
|
Guide/Conveyor | Any |
High Abrasion resistant. Weather resistant |
|
Nip Roller | Any |
High Modulus. Weather resistant |
|
Silicone Roller | Any |
Heat resistance upto 210 deg celcius over the rubber surface. |
|
Ebonite Roller | Any |
Black and Non black Ebonites with heat resistance |
|
Poly Urethane Roller | Any |
Outstanding Abrasion resistance. Good oil resistance |
|
Viton Roller | Any |
Very high heat and oil resistance. |
|
Epichlorohydrin rollers | Any |
Very low compression set. High oil resistance |
